TL;DR: DFlash replaces sequential speculative decoding with parallel block diffusion, achieving 600 tokens/sec on a single RTX 5090 running Gemma 4 26B A4B MoE. The draft model proposes 8 tokens in one forward pass instead of 8 sequential passes, yielding 3.4x speedup over standard autoregressive generation.
Standard autoregressive LLM inference generates one token at a time. Every new token requires a full forward pass through the network. This sequential bottleneck wastes the massive parallel compute capabilities of modern GPUs.
Speculative decoding attacks this problem: a small “draft” model predicts multiple tokens ahead, then the larger “target” model verifies them in a single parallel pass. The idea is not new — EAGLE, Medusa, and Lookahead Decoding all explore it. But DFlash changes the game by eliminating the sequential drafting bottleneck entirely.
The Bottleneck: Sequential Drafting
Traditional speculative decoding works like this:
- Draft model generates token A
- Draft model generates token B (using A as context)
- Draft model generates token C (using B as context)
- … repeat until N draft tokens are produced
- Target model verifies all N tokens in parallel
The problem: steps 1-4 are still sequential. Even with a tiny draft model, generating 8 tokens requires 8 forward passes. The draft model becomes the new speed limit.
DFlash eliminates this by using block diffusion — the draft model produces all 8 tokens simultaneously in a single forward pass, conditioned on hidden states from the target model.
How DFlash Works
DFlash is developed by Z Lab at UC San Diego (led by Zhijian Liu, Jian Chen, and Hao Zhang — co-inventor of paged attention). It replaces the autoregressive drafting loop with a non-causal attention mechanism.
Architecture
The target model (Gemma 4 26B) produces hidden states during its forward pass. These “fused target context features” are extracted and combined with mask token embeddings. The draft model then processes both simultaneously using bidirectional attention — each position attends to the target’s hidden states and all other draft positions at once.
The output is projected through the target model’s LM head to produce vocabulary logits for speculative decoding verification.
Key Differences from EAGLE-3
| Aspect | EAGLE-3 | DFlash |
|---|---|---|
| Drafting | Sequential autoregressive | Parallel block diffusion |
| Forward passes per block | K passes (one per token) | 1 pass (entire block) |
| Typical K | 2 | 10-15 |
| Target-conditioned | No | Yes (hidden states) |
| Attention mask | Causal | Non-causal (bidirectional) |
On TPU v5p benchmarks, DFlash achieved 2.29x speedup versus EAGLE-3’s 1.30x — nearly doubling the performance gain.
Gemma 4 26B A4B: MoE Advantage
The demo uses Gemma 4 26B A4B, a Mixture-of-Experts model from Google. The “A4B” designation means 4 billion active parameters out of 26 billion total.
MoE Routing
Each token is routed through only a subset of expert layers. During any single forward pass, approximately 4 billion parameters process the input while the remaining 22 billion remain dormant. This has two critical implications:
- Latency scales with active parameters, not total size — 4B activation budget means compute throughput matches a much smaller dense model
- VRAM footprint remains at full capacity — all 26B parameters must be resident in GPU memory for fast expert routing
The model uses 128 fine-grained experts with top-8 routing, meaning each token activates 8 of 128 experts per layer.
Why MoE Excels with Speculative Decoding
MoE models are ideal candidates for speculative decoding because:
- The active parameter count is small enough for rapid verification passes
- Expert routing creates predictable patterns that draft models learn effectively
- The 26B capacity provides high-quality outputs while 4B active parameters keep latency low
Setup: vLLM + DFlash on RTX 5090
The demo runs on a single NVIDIA RTX 5090 (16GB VRAM) using AWQ 4-bit quantization. Here’s the configuration:
Model Loading
- Target:
cyankiwi/gemma-4-26B-A4B-it-AWQ-4bit(community AWQ 4-bit quantization) - Draft:
z-lab/gemma-4-26B-A4B-it-DFlash(DFlash speculator from V Lab) - Engine: vLLM with
VLLM_USE_FLASHINFER_SAMPLER=0(FlashInfer disabled for DFlash compatibility)
Speculative Decoding Flags
The full command from the demo:
VLLM_USE_FLASHINFER_SAMPLER=0 vllm serve \ cyankiwi/gemma-4-26B-A4B-it-AWQ-4bit \ --speculative-config '{ "method": "dflash", "model": "z-lab/gemma-4-26B-A4B-it-DFlash", "num_speculative_tokens": 8, "attention_backend": "flash_attn" }' \ --max-num-seqs 1 \ --max-num-batched-tokens 8192 \ --max-model-len 2048 \ --gpu-memory-utilization 0.93 \ --kv-cache-dtype fp8 \ --trust-remote-codeKey flags:
| Flag | Purpose |
|---|---|
VLLM_USE_FLASHINFER_SAMPLER=0 | Disable FlashInfer sampler (DFlash compatibility) |
--speculative-config | JSON block: method, draft model, token count, attention backend |
--max-num-seqs 1 | Single sequence (no batching) |
--max-num-batched-tokens 8192 | Token batch limit |
--max-model-len 2048 | Context window size |
--gpu-memory-utilization 0.93 | Use 93% of VRAM |
--kv-cache-dtype fp8 | FP8 KV cache (saves memory vs FP16) |
--trust-remote-code | Allow custom repo code (AWQ quantization) |
Hardware Metrics (from demo)
| Metric | Value |
|---|---|
| GPU | RTX 5090 |
| VRAM Usage | ~29 GB (with quantization) |
| GPU Utilization | 99% |
| Power Draw | ~400 W |
| Draft Throughput | ~1,000 tok/s |
| Main Model Throughput | ~255 tok/s |
| Peak Output | 600 tok/s |
The VRAM usage of ~29GB is impressive — the 26B model in AWQ 4-bit fits within the RTX 5090’s 16GB VRAM plus system memory, thanks to efficient quantization and MoE activation patterns.
Benchmark Results
The demo compared baseline (no speculative decoding) versus DFlash across different output lengths:
Short Outputs (128 tokens)
- Baseline: ~255 tok/s
- DFlash: ~350 tok/s
- Speedup: ~1.4x
Long Outputs (1024 tokens)
- Baseline: ~255 tok/s
- DFlash: ~600 tok/s
- Speedup: ~2.3x
DFlash benefits more from longer generation tasks because the draft quality compounds over many steps. Each speculative step saves multiple forward passes, and those savings accumulate across the sequence.
Acceptance Rate: The Hidden Metric
The demo revealed a critical metric: draft acceptance rate.
- Draft model proposes: 9,000 tokens
- Main model accepts: 1,764 tokens
- Acceptance rate: ~18.3% (mean acceptance length ~7.8 per step)
This seems low, but it’s actually efficient. The 18.3% figure represents overall acceptance across all drafted tokens (1,764 accepted out of 9,000 proposed). The mean acceptance length of ~7.8 per step means that on average, nearly all 8 drafted tokens are accepted consecutively before the main model intervenes. Since the draft costs only one forward pass (versus 8 sequential passes for EAGLE-3), this translates to massive throughput gains.
The acceptance rate varies by task type:
- Math/coding: High acceptance (~25-30%) — predictable token sequences
- Creative text: Lower acceptance (~15-20%) — more stochastic generation
- Chat: Moderate acceptance (~18%) — position-dependent decay
Trade-offs
When DFlash Wins
- Long-form generation (code, documentation, HTML)
- High-end GPUs with sufficient VRAM for both models
- Tasks with predictable token sequences (math, coding)
- Throughput-critical serving scenarios
When DFlash Falls Short
- Consumer GPUs under 16GB VRAM (both models must fit)
- Short QA pairs (minimal relative gain)
- Zero-friction deployments (requires vLLM dev branch)
- Temperature > 0.7 (draft quality degrades with randomness)
Integration Complexity
Unlike EAGLE or Medusa, DFlash requires:
- Separate drafter model download
- Custom vLLM build (development branch)
- Attention backend configuration (Triton for main, Flash for draft)
- Careful VRAM management
SGLang has more stable DFlash support for production serving, while vLLM integration is maintained by NVIDIA contributors in a development branch.
The RTX 5090 Factor
The demo runs on an RTX 5090, which offers 16GB GDDR7 VRAM. Key advantages:
- Memory bandwidth: ~1.5 TB/s (GDDR7) enables rapid weight loading
- Tensor cores: 4th generation for FP8/INT4 acceleration
- Power efficiency: 400W draw with near-4B active parameters
For comparison, datacenter benchmarks on H100 (80GB) achieve 222 tok/s with DFlash + Gemma 4 — the RTX 5090 nearly triples this despite having 5x less VRAM, thanks to quantization and MoE activation patterns.
Cost Analysis
Running inference locally eliminates per-token API costs entirely:
| Approach | Cost per 1M tokens | Hardware | Speed |
|---|---|---|---|
| OpenAI API (GPT-4o) | ~$15 | Cloud | 100-200 tok/s |
| Google API (Gemma 4) | ~$0.20-0.50 | Cloud | Variable |
| Local RTX 5090 + DFlash | ~$0 (after purchase) | Consumer | 600 tok/s |
| Local H100 + DFlash | ~$0 (after purchase) | Datacenter | 222 tok/s |
The RTX 5090 (~$2,000) pays for itself after approximately 10 million tokens generated, making it cost-effective for heavy local inference workloads.
References
- 600 Toks/Second Gemma4-26B — The Setting That Actually Wins — Tech-Practice, YouTube (May 8, 2026) — https://www.youtube.com/watch?v=S_zbHH5Ycs0
- DFlash: Block Diffusion for Flash Speculative Decoding — Chen, Jian; Liang, Yesheng; Liu, Zhijian, arXiv (February 2026) — https://arxiv.org/abs/2602.06036
- DFlash Speculators Documentation — vLLM Project — https://docs.vllm.ai/projects/speculators/en/latest/user_guide/algorithms/dflash/
- Deploying DFlash Speculative Decoding with Gemma 4 26B A4B on vLLM — Claudiu RAVEICA, RavChat (May 9, 2026) — https://www.ravchat.com/deploy-dflash-speculative-decoding-vllm
- Supercharging LLM inference on Google TPUs: Achieving 3X speedups — Yarong Mu, Lihao Ran, Google Developers Blog (May 4, 2026) — https://developers.googleblog.com/supercharging-llm-inference-on-google-tpus-achieving-3x-speedups-with-diffusion-style-speculative-decoding/
- Gemma 4 Model Overview — Google AI for Developers — https://ai.google.dev/gemma/docs/core
- z-lab/gemma-4-26B-A4B-it-DFlash — Hugging Face — https://huggingface.co/z-lab/gemma-4-26B-A4B-it-DFlash
- When Speculative Decoding Helps Local LLMs — Allen Kuo, Medium — https://allenkuo.medium.com/when-speculative-decoding-helps-local-llms-and-when-it-doesnt-5c41dd804e4b
